22-cubic-meter CHENGLONG garbage compactor truck, with a 10-ton load capacity

Product code: ER-CHENGLONG-22K
Group: Garbage compactor truck
Style: Garbage truck
Gross Vehicle Weight Rating: 24000 kg
Wheel construction formula: 4x4 (2 axles, 2 driven axles)
Manufacturer: Chenglong
Payload range: From 8 tons and up
Price range: From 1 billion to under 1.5 billion VND

Details of 22-cubic-meter CHENGLONG garbage compactor truck, with a 10-ton load capacity

Introduction 22-cubic-meter CHENGLONG garbage compactor truck, with a 10-ton load capacity

The Chenglong 22m³ garbage compactor truck is a premium product in the large-capacity garbage compactor line. Equipped with advanced garbage compaction technology and powerful engine, the product has the ability to compress waste with high compression ratio and optimal transportation efficiency.

Modern design and automatic control system help operators use easily. The product is particularly suitable for waste collection in large urban areas, shopping centers and industrial zones.

Detailed Technical Specifications: 22-cubic-meter CHENGLONG garbage compactor truck, with a 10-ton load capacity

Below are the complete technical specifications and detailed information of the product:

STT	Content	Detailed specifications
A	VEHICLE PART
1	Vehicle type	Garbage truck
2	Number of types
3	Brand	CHENGLONG
4	Emission standards	Euro V
5	Vehicle quality	100% new
6	Country of origin	Vietnam
7	Year of vehicle assembly	2025
8	Year of manufacture of completed vehicle	2025
9	Total mass	24,000 Kg
10	Dead weight	13,305 Kg
11	Cargo volume	10.50 0 Kg
12	Car size LxWxH	9 . 3 0 0 x 2 .50 0 x 3 .50 0 mm
13	Inner dimensions of the box LxWxH	4,700/4,400 x 2,290/1,960 x 2,100 mm
14	Axle distance	4,500 + 1,350 mm
15	Hill climbing ability	34%
16	Ground clearance	2 8 0 (mm)
17	maximum speed	99 km/h
18	Number of seats	03 ( people)
19	Cabin	White, flip-up, air-conditioned, central electric windows.
20	Engine
-	Type	YC6A270-50
-	Cylinder capacity	7,520 (cc )
-	Compression ratio
-	Cylinder diameter x Piston stroke	110 x 132 (mm)
-	Maximum capacity	199 kw /2.300 rpm
-	Maximum torque	1300 / 160 0 Nm/rpm
-	Fuel type, number of strokes, number of cylinders, layout, cooling type	Diesel, 4-stroke, 6-cylinder in-line, turbocharged, water-cooled
21	Fuel tank	200 liters
22	Gear	Manual transmission, 9 forward gears, 1 reverse gear, synchronized .
23	Clutch	Single disc dry friction spring type, hydraulic drive, pneumatic assist
24	Suspension system
-	Front tweezers:	Dependent, leaf spring, hydraulic shock absorber .
-	Rear leaf spring:	Dependent, leaf spring.
25	Brake system
-	Main brake:	Drum, 2-line pneumatic
-	Hand brake:	Mechanical, pneumatic with exhaust backup brake
26	Steering system	Recirculating ball screw type, full hydraulic power assist . Tilt angle and height can be adjusted.
27	Tire size	11:00 – R20 – 16 PR (11 cakes)
28	steering mechanism type	Screw – Ball nut, Hydraulic power steering
29	Electrical system
-	Generator	24V – 60A
-	Starter	24V
-	Battery	12Vx02
B. SPECIALIZED SYSTEM FOR WASTE COMPRESSION 22-cubic-meter CHENGLONG garbage compactor truck, with a 10-ton load capacity
1	Container volume	22 m ³(K exchange)
2	Garbage collection control	Mechanical, hand lever control.
3	Control of garbage compactor	Semi-automatic mechanical, hand-operated
4	Litter control	Mechanical, hand lever control.
5	Garbage disposal mechanism	Use hydraulic cylinders combined with trash push rails .
6	Garbage loading mechanism	Hydraulic control mechanics
7	Hydraulic pump	Type : Piston Pump (Curved Pump) . Imported from ITALY
8	Tail limit lifting and trash pushing control valve	Imported from ITALY
9	Control valve to press and raise and lower the trash chute	Imported from ITALY
10	Single hydraulic cylinder	Materials and components imported from Italy, manufactured and assembled in Vietnam:
11	Stage hydraulic cylinder	Imported materials and components. Origin: ITALY , assembled in Vietnam.
12	Throttle valve	Imported from ITALY
13	Safety valve	Imported from ITALY
14	Return valve	Imported from ITALY
15	Anti-sink valve	Imported from ITALY
16	Hydraulic oil tank	Capacity: 150 liters.
17	Electrical equipment and warning system
-	Priority rotating light	Quantity 01 piece, placed on top of the box.
-	Work position lighting behind the trash compactor.	Switch installed at control position. - Quantity 01 piece in the box. - Quantity: 02 pieces on top of the tail of the box
-	Other traffic light systems	According to road traffic standards.
18	Safety equipment
-	Footholds and handrails	Equipped with pedals and handrails on both sides behind, enough room for workers to operate, ensuring labor safety.
-	Safety bar	02 trash compactor bars, ensuring safety during cleaning and maintenance .
-	Hip insurance	02 side protection bumpers
-	Mudguard	02 mudguards
-	Anti-bucket bowl	0 6 bowls , 04 dishes
19	Wastewater sealing and containment system
-	Water collection system	Across the body of the car
-	Seal the trash can	Staggered installation in layers , with inclined corners to catch water - lead water down to the tank (high durability, no damage )
-	Waste water tank	Equip a waste water tank below the press tank. There is 01 wastewater discharge valve and 02 quick-action doors for cleaning the wastewater tank.
20	Logo-lettering	Side of the truck
21	Vehicle equipment	01 spare wheel ; 01 hydraulic jack and wrench ; 01 CD player and AM/FM radio ; 01 standard tool set ; warranty book, user manual.
22	Guarantee
-	Base vehicle :	Warranty period according to the regulations of the importer CHENGLONG
-	Specialized part:	Warranty period within 12 months unlimited km from the date of acceptance and put into use.
